Especificaciones técnicas

'
• Interfaz
'
'
• 24 x 10/100/1000BASE-T
'
• 4 x 100/1000Mbps combo
'
'
• Estándar
'
'
• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
'
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
'
• IEEE 802.3u 100BASE-FX 100 Mbps over fiber optic
'
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper)
'
• IEEE 802.3z 1000BASE-X 1 Gbps over fiber optic
'
• IEEE 802.3az Energy Efficient Ethernet (EEE)
'
• IEEE 802.3x Flow Control
'
'
• Cables Red
  '
'
'
• UTP Cat. 5, Cat. 5e (100 m max.)
  '
'
'
• Duplex Mode
  '
'
'
• Full/Half-duplex for 10/100 Mbps
  '
'
• Full-duplex for 1000 Mbps
  '
'
'
• Interfaz Media Intercambio
  '
'
'
• Ajuste automático MDI/MDIX para todos los puertos de par trenzado
  '
'
'
• Ahorro de energía
'
'
• Link Status detection
'
• LED Shut-Off
'
• Port Shut-Off
'
• System Hibernation
'
• Time-based PoE (DGS-1210-10P/28P/52P/52MP only)
'
'

• Seguridad

  '
'
'
• Access Control List secures network
'
• D-Link Safeguard Engine protects CPU from Broadcast/Multicast/Unicast Flooding
'
• Port Security supports 64 MACs per port
'
• ARP Spoofing Prevention
'
'

• Intuitive Management

  '
'
'
• D-Link Network Assistant Utility or Web-based GUI
'
• Built-in SNMP MIB for remote NMS (D-View 6.0)
'
• Compact CLI through Telnet
'
'

• Prestaciones avanzadas

  '
'
'
• Auto Surveillance VLAN
'
• Loopback Detection automatically disables a port when a loop is detected
'
• Cable Diagnostics allows administrators to determine cable status
'
• SFP ports for flexibility
'
• Auto MDI/MDIX
'
'

• Interface

  '
'
'
• Puertos 10/100/1000BASE-TX
'
• DGS-1210-28 - 24 puertos
'
• Puertos SFP
'
• DGS-1210-28 - 4 puertos
'
'

• Rendimiento

  '
'
'
• Switch Capacity
'
• DGS-1210-28- 56 Gbps
'
• 64-Byte Packet Forwarding Rate
'
• DGS-1210-28 - 41.7 Mpps
'
• MAC Address Table Size
'
• 16K
'
• Packet Buffer
'
• DGS-1210-10/20/28- 1.5 MB per device
'
'

• Consumo (Standby/Maximum)

  '
'
'
• DGS-1210-28 - 17.84W / 22.45W
'
'

• Power Input

  '
'
'
• 10 to 240 VAC, 50/60HZ
'
'

• Dimensiones (W x D x H)

  '
'
'
• DGS-1210-28 - 440 x 140 x 44 mm
'
'

• Peso

  '
'
'
• DGS-1210-28 - 1.67 kg
'
'

• Certificaciones

  '
'
'
• CE Class A, VCCI Class A, FCC Class A, cUL, CE (LVD), BSMI, CCC, C-Tick
'
'
